CC-28V

The electrohydraulic power pack type CC-28V is supplied with electric motor 12V or 24V – 1000W-1500Rpm, vertical 28 litre tank, solenoid valve, non-return valve, central manifold with adjustable max pressure valve, gear pump, filter, pressure gauge with exclusion and all that is needed for a correct functioning.
This type of power pack is equipped with a flexible coupling between gear pump shaft and motor which guaranties high durability.
For such reason it is mainly used for working vessels and/or ships with very high workload.
The flow rate must be dimensioned according to the hydraulic cylinder and to the requested pressure.

UPON REQUEST
– Flow regulator
– Painted white

DOWNLOAD PDF FILE
